Sidewinder-Byte
Fully Rugged Ultra-Compact Embedded Computer. Ultra-Small and Rugged for Unlimited Deployment Capability
Sidewinder-Byte
Sidewinder-Byte is an ultra-small-form-factor embedded edge computer, purpose-built for deployment into austere environments and SWaP-optimized for integration into any vehicle or platform. Sidewinder-Byte provides the advanced computing capability and ruggedization demanded for mission-critical applications, with a modular and expandable design to meet exacting customer specifications. Sidewinder-Byte is engineered with a standards-based approach utilizing open architectures and COTS technologies, and is aligned to OSA/MOSA mandates. Sidewinder-Byte is engineered and manufactured for extreme SWaP optimization providing significant capabilities in a compact, fully rugged embedded edge computer.
Features
- USFF SWaP-Optimized 6.30”W x 6.00”D x 2.25”H (base model)
- Intel x86 Atom CPU
- Dense IO including multiple GbE, USB, serial
- Onboard and removable storage (slice) options
- Modular expansion “slice” design
- MOSA-aligned
Environmentals
- Fully rugged and sealed
- Operating temperature: -40C to +75C (configuration dependent)
- MIL-STD-810H Shock | Vibration | Altitude | Humidity | Sand and Dust | Fluids/Rain
- MIL-STD-461G EMI/EMC
- MIL-STD-1275E/704F 28VDC Power (no power hold-up)
- IP66 sealed
Applications
- Uncrewed and autonomous aerial, ground, and maritime vehicles/systems
- Robotic combat vehicles
- Airborne law enforcement
- Inspection and monitoring
- Industrial IoT (IIoT)
- Network distribution and other gateway device applications
