Hawk-Strike IV

Fully Rugged Multi-Mission Embedded Computer. High-performance workstation-class single line replaceable unit (LRU) solution

Hawk-Strike IV

Hawk-Strike IV is a fully rugged, single line replaceable unit (LRU) embedded edge computer purpose-built for deployment in harsh environments for demanding defense and commercial applications. Featuring the latest Intel Core or Xeon mobile CPUs and NVIDIA embedded GPUs, Hawk-Strike IV provides workstation performance in a SWaP-optimized system deployable in any environment and on any platform. Hawk-Strike IV offers robust IO and system expansion for a true single LRU solution with centralized and converged sensor ingest, processing, networking, storage, controls, and distribution – supporting the mission with reliable tactical processing and communications enabling capabilities. Hawk-Strike IV is fully rugged and sealed, and is passively cooled (no moving parts) with an extended operating temperature range. Hawk-Strike IV is engineered with a standards-based approach utilizing open architectures and COTS technologies, and is aligned to OSA/MOSA mandates.

  • SFF SWaP-optimized 8.50”W x 13.25”D x 5.10”H
  • Latest Intel mobile CPU
    • Standard: Xeon E-2276ML
  • Latest NVIDIA embedded GPU
    • Standard: GeForce 1050Ti or Quadro RTX3000
  • Up to 64GB dual-channel DDR4 (ECC with Xeon CPU)
  • Base system IO: multiple GbE, USB 3.0, USB 2.0, serial, DVI, audio
  • Robust system expansion options including multi-port and multi-format video capture/encode, multi-port GbE switch/NIC, CAN, ARINC-429, 1553, GPS
  • Dual high-capacity removable 2.5” SSDs; options for internal mSATA storage
  • MOSA-aligned
  • Fully rugged and sealed
  • Operating temperature: -40C to +60C (configuration dependent)
  • MIL-STD-810H Shock | Vibration | Altitude | Humidity | Sand and Dust | Fluids/Rain | Explosive Atmosphere
  • MIL-STD-1275E/704F 28VDC Power (no power hold-up)
  • DO-160G  various
  • IP66 sealed
  • Centralized mission processor
  • Force protection
  • Aided target recognition (AiTR)
  • 360 degree situational awareness (360SA)
  • Command, control. communication, computers, cyber, intelligence, surveillance, and reconnaissance (C4ISR)
  • Media recorder
  • Airborne law enforcement (ALE)
  • Crew station compute
  • Command and control (C2)
  • Vehicle electronics (VETRONICS)
  • Uncrewed/unmanned and autonomous aerial, ground, and maritime vehicles/systems
